The HW sealed connector series is a new, improved version of the conventional HM sealed series, with a mechanism that detects when terminals are not inserted completely.

This series consists of a 090 type classififi ed according to terminal size, supporting use in a variety of control circuits and low power circuits.

-The connector mechanism only allows the retainer to be set when the terminal is completely inserted.

-These connectors can be directly secured to a bracket on the car body.

-1-6 way connectors adopt an inertia locking system to prevent semi-engagement.

-8-14 way connectors is only possible when the locking mechanism ensures the connectors are completely engaged, preventing semi-engagement.

The Part No. of HW Sealed series as follow, we have the stocks for this full series, for more details, you can contact us by email anytime

1 Way: 6181-0227 , 6189-0386

2 Way: 6181-0070 , 6189-0129

3 Way: 6181-0071 , 6189-0130 , 6181-0072 , 6189-0131

4 Way: 6181-0073 , 6189-0132

6 Way: 6181-0074 , 6189-0133

8 Way: 6181-0075 , 6189-0134

10 Way: 6181-0076 , 6189-0135

14 Way: 6181-0077, 6189-0136
